Applications
This 1.5 reel fire hose is designed for use in conjunction with reels, hump rack, cabinets or other fire protection equipment.
Pressure Ratings
250 lb.# Service Test Pressure Rating
500# lb. Proof Test Pressure Rating
750# lb. Burst Pressure Rating
Construction
Made with high-quality materials, our 1.5″ reel fire hose boasts a 100% polyester single woven jacket with a single ply urethane/ thermoplastic lining.
Temperature Range
-40° F to 180° F
-40° C to 82° C
Special Characteristics
FM Label
At Rawhide Fire Hose, our standard fire hose lengths come coiled, never needs drying and are impervious to mildew.
Hose Size: 1.5″
Bowl Size: 1.68 (or 1–11/16″)
Weight per 50′ Uncoupled: 5 lbs.
Description
At Rawhide Fire Hose, we offer 1.5″ reel fire hose (500 lb. pressure test) that is designed to be lightweight while offering maximum flow for all your indoor reel fire hose needs. Our coiled reel fire hose can be used in conjunction with reels, hump rack, cabinets or other indoor fire protection equipment. Our 1.5″ reel fire hose is available with the following pressure ratings:
- 250 lb# Service Test Pressure Rating
- 500# lb Proof Test Pressure Rating
- 750# lb Burst Pressure Rating
Chemical Resistant Single Jacket Reel Fire Hose
Our reel fire hoses feature a single jacket construction woven from 100% virgin polyester that is resistant to most chemicals, petroleum products, UV exposure and mildew.
The lining of each reel fire hose is a single-ply extruded tube of synthetic polyurethane /thermoplastic (T.P.U.), designed to be light weight for ease of operator use and increase packing ability for interior firefighting applications. The liner of these reel fire hoses produces a thin, smooth waterway that yields extremely low friction loss for maximum flow rates. The reel hose manufacturing process ensures positive adherence to the jacket to prevent de-lamination.
Reel Fire Hoses Available in a Variety of Specifications
Our reel fire hose is available with internal expansion ring-type threaded aluminum or brass. Standard thread patterns for these reel hoses are NH/NST or IPT/NPSH, custom threads are available upon request, Contact TEAM RAWHIDE. All rack hoses are temperature rates for -40°F to 180°F (-40°C to 82°C).
Our reel fire hoses are FM approved and labeled, and meet or exceed Underwriters Lab (U.L.) and NFPA 1961. While standard lengths for these reel hoses are 50’, 75’, and 100’. All hoses are stenciled with 1” characters stating, “Service Test to 250 PSI per NFPA 1962 ” and the service date in a contrasting color, indelible ink. Please refer to your states’ “revised codes” and/or the local fire marshal to confirm compliance with regulations.
